Description
Side elevation of a five-axle all terrain mobile crane with its telescopic boom raised, fly jib stowed alongside and the hook block lowered on the falls. The carrier is drawn with all outriggers extended and jacked, plus the counterweight stack, operator cab and superstructure. Useful for site establishment plans, lift studies and crane access drawings. A free AutoCAD DWG file download.
