Description
A metal shelf drawn in plan view – the shelf outline with corner post markers at all four corners, the standard footprint for freestanding storage racking. Deliberately plain: on a plan, shelving is a footprint and a label.
Array it to lay out storerooms, archives, garages and back-of-house retail areas – aisle clearances between runs are the design decision this block makes visible. The cupboard and bookshelf blocks on this site cover the joinery cases. A free AutoCAD DWG file download.
