Description
A boat gangway loading ramp drawn as a dimensioned arrangement – the curved truss-sided gangway in elevation with its handrail panels and kick plates, plus an end section showing the channel profile and fixing detail. A genuine marine engineering drawing rather than a symbol.
Use it in marina and wharf documentation, vessel access designs and mechanical handling drawings – adapt the spans and rail heights to your site. More mechanical and marine items live on this site. A free AutoCAD DWG file download.
