A hand pallet truck (pallet jack) drawn and dimensioned in plan and side elevation – forks, steer wheels, load rollers and handle shown, with overall length, fork spread and height dimensions included. The dimensions make this more than a symbol: it documents the actual clearance envelope of the equipment.
Use it in warehouse aisles, coolroom and back-of-house layouts, dock leveller details and goods-lift sizing checks – anywhere manual pallet movement drives the design clearances. A free DWG file for AutoCAD and compatible software.
