Description
Braced variant of the steel ground-mount solar PV frame, drawn as a plan, a side elevation at 14 degree fixed tilt, and module dimensions. This version adds ISA 35X35X3 diagonal side bracing and a 240X80X5 coupler plate to the ISLC 75X40 column posts, ISA 50X50X3 rafter and 60CSX40X10X2 purlins. A free AutoCAD DWG file download.
