Description
Section detail at 1/2" = 1'-0" showing new 28" open web steel joists tied into an existing 8" concrete block wall with no parapet, seated in cut joist pockets on a bearing plate. New roof construction, flashing and membrane are noted to match and seal to the existing roof. A free AutoCAD DWG file download.
