Description
An air reservoir mechanical symbol – the horizontal capsule (rounded-end cylinder) with connection lines each side, the schematic element for compressed air receivers on services drawings. Drawn to standard symbol convention at annotation weight.
Use it on compressed air schematics, pneumatic system diagrams and plant room documentation. The mechanical symbol category on this site carries the companion valves, filters and drains for complete air services schematics. A free AutoCAD DWG block download.
