Free AutoCAD Blocks
A comprehensive library of imperial steel angle (L-section) blocks, covering equal and unequal angles from 1x1x1/8 up to 9x4x5/8 inch, with each size drawn in three views — end (cross-section), plan and side — and labelled with its dimensions. A handy reference for steel detailing and structural drafting. A free AutoCAD DWG file download.
| File format | DWG – opens in AutoCAD and all DWG-compatible CAD software |
|---|---|
| File size | 1.46 MB |
| Files included | 11 |
| Categories | Steel, Structural |
| License | Free for personal and commercial use – no attribution required |
| File | |
|---|---|
| Angles 1x1xd125 to 2x2xd375.dwg | Download |
| Angles 2d5x2xd1875 to 3x2xd375.dwg | Download |
| Angles 3d5x3d5xd375 to 4x3d5xd4375.dwg | Download |
| Angles 3x2xd4375 to 3x3xd4375.dwg | Download |
| Angles 3x3xd5 to 3d5x3d5xd3125.dwg | Download |
| Angles 4x3d5xd5 to 5x3xd4375.dwg | Download |
| Angles 5x3xd5 to 5x5xd5.dwg | Download |
| Angles 5x5xd625 to 6x4xd75.dwg | Download |
| Angles 6x4xd875 to 7x4xd625.dwg | Download |
| Angles 7x4xd75 to 8x8xd5.dwg | Download |
| Angles 8x8xd5625 to 9x4xd625.dwg | Download |
