Free AutoCAD Blocks
A comprehensive library of imperial steel S-shape blocks — American Standard beams, the tapered-flange I-sections — covering sizes from 3x5.7 up to 24x121 (depth in inches by weight in pounds per foot), with each size drawn in three views — end (cross-section), plan and side — and labelled with its designation. A handy reference for steel detailing and structural drafting. A free AutoCAD DWG file download.
| File format | DWG – opens in AutoCAD and all DWG-compatible CAD software |
|---|---|
| File size | 392.14 KB |
| Files included | 4 |
| Categories | Steel, Structural |
| License | Free for personal and commercial use – no attribution required |
| File | |
|---|---|
| S-Shapes 3x5d7 to 6x17d25.dwg | Download |
| S-Shapes 7x15d3 to 12x35.dwg | Download |
| S-Shapes 12x40d8 to 20x75.dwg | Download |
| S-Shapes 20x86 to 24x121.dwg | Download |
