Free AutoCAD Blocks
A comprehensive library of imperial steel tube blocks — rectangular and square hollow structural sections (HSS) — covering sizes from 2x2x3/16 up to 20x12x5/8 (width by height by wall thickness in inches), with each size drawn in three views — end, side and top — and labelled with its designation. A handy reference for steel detailing and structural drafting. A free AutoCAD DWG file download.
| File format | DWG – opens in AutoCAD and all DWG-compatible CAD software |
|---|---|
| File size | 2.70 MB |
| Files included | 13 |
| Categories | Steel, Structural |
| License | Free for personal and commercial use – no attribution required |
| File | |
|---|---|
| Tubing 2x2x3_16 to 4x3x1_4.dwg | Download |
| Tubing 4x3x5_16 to 5x5x3_16.dwg | Download |
| Tubing 5x5x1_4 to 6x5x3_8.dwg | Download |
| Tubing 6x5x1_2 to 7x5x1_4.dwg | Download |
| Tubing 7x5x5_16 to 8x4x5_16.dwg | Download |
| Tubing 8x4x3_8 to 9x3x1_2.dwg | Download |
| Tubing 9x5x3_16 to 9x9x3_16.dwg | Download |
| Tubing 9x9x1_4 to 10x5x5_8.dwg | Download |
| Tubing 10x6x3_16 to 10x10x5_8.dwg | Download |
| Tubing 12x2x3_16 to 12x8x1_2.dwg | Download |
| Tubing 12x8x9_16 to 14x14x5_16.dwg | Download |
| Tubing 14x14x3_8 to 20x4x5_16.dwg | Download |
| Tubing 20x4x3_8 to 20x12x5_8.dwg | Download |
