Section detail of an L-2 header in a masonry block wall, showing the 6 by 12 inch header with two horizontal rebar, bearing on full vertical grout channels each side of the opening. Includes the top plate, J-bolt fixing and hatch legend for the channel types. A free AutoCAD DWG file download.
| File format | DWG – opens in AutoCAD and all DWG-compatible CAD software |
|---|---|
| File size | 52.62 KB |
| Files included | 1 |
| Categories | Masonry, Structural, Structural Details |
| License | Free for personal and commercial use – no attribution required |
