Section detail of a J-hook rebar attachment in a masonry block wall, showing the hook engaging the top horizontal rebar at 48 inch centres between J-bolts, within the 6 by 6 inch continuous bond beam over a grouted vertical channel. A free AutoCAD DWG file download.
| File format | DWG – opens in AutoCAD and all DWG-compatible CAD software |
|---|---|
| File size | 50.90 KB |
| Files included | 1 |
| Categories | Masonry, Structural, Structural Details |
| License | Free for personal and commercial use – no attribution required |
