Description
Unequal Angle (UA) hot-rolled steel sections drawn as accurate profile linework – the L-section with one long and one short leg, true root and toe radii, based on the 150 × 90 × 8 profile. The download includes 16 DWG files covering the standard Australian UA size range, one per section.
Use them in connection details, shelf and lintel angles, framing details and fabrication drawings wherever the legs must differ. The equal angle set and the full UB/UC/PFC library are in the steel category on this site. A free AutoCAD DWG download.
