Description
Reinforced concrete pile cap detail in section and plan, showing a 2800 x 2800 octagonal cap with chamfered corners carried on a group of seven 350 x 350 piles, reinforced with D19-150 and D19-100 bars and 2D13 side bars. The blinding, compacted sand and compacted subgrade layers beneath are noted. Annotations are in Indonesian. A free AutoCAD DWG file download.
