A sheet of fully annotated roof and wall section details for timber framed construction, covering the eave and gutter, a ridge with enlarged callout, and wall junctions at floor level, each set out with the full build-up of cladding, insulation, framing and linings. A free AutoCAD DWG file download.
| File format | DWG – opens in AutoCAD and all DWG-compatible CAD software |
|---|---|
| File size | 141.77 KB |
| Files included | 1 |
| Categories | Architectural Details, Structural Details |
| License | Free for personal and commercial use – no attribution required |
