Description
A bathroom basin (Type 1) drawn in three views across three DWG files – plan of the semicircular bowl with twin taps, front elevation showing the shallow profile, and side elevation with the wall bracket and trap. A wall-hung basin with no pedestal, drawn at true proportions.
Use the plan on layouts and the elevations on internal elevations and hydraulic details. It opens the eight-type basin range on this site – pick the profile matching the specified fixture. A free AutoCAD DWG download.
