Description
A bathroom basin (Type 6) drawn in three views across three DWG files – plan of the squared-off bowl with twin soap dishes, front elevation on its pedestal with mixer tap, and side elevation showing the bracket fixing and P-trap waste pipework.
Use the plan on bathroom and ensuite layouts and the elevations on internal elevations and hydraulic details. One of eight basin types on this site – each drawn with a distinct bowl profile so the block can match the specified fixture. A free AutoCAD DWG download.
