Description
A toilet suite (WC, Type 3) drawn in three views across three DWG files – a wall-hung pan with concealed cistern: plan of the open-front seat, front elevation with the slim cistern above, and side elevation showing the cantilevered pan clear of the floor.
Wall-hung suites are the commercial and premium-residential standard, and the clear floor under the pan matters for cleaning specs. Use the plan on layouts and the elevations on internal elevations and in-wall cistern details. A free AutoCAD DWG download.
